AJR
AFV2128 Film Viewer
AFV2128 Film Viewer
- Brand
- AJR
- Category
- Radiography Testing
- Method / product family
Technical Specifications
| Max. Light Intensity | 0-100.000 Cd/㎡ adjustable; 0 -300,000 Cd/㎡adjustable |
|---|---|
| Control Mode: | Manual / foot-switch |
| Dimmer Control | 0% to 100% continuous |
| Film Density: | > 4.5 density (More than 4.5 D) |
| Uniform Viewing Area: | 98% full Screen |
| Cooling Method: | Air cooling |
| Surface Temperature Rise: | < 18° Continuous operation for 24 hours |
| LED Light Life | 50,000 Hours |
| Size of Viewing Window | 220mm*80mm (L×W) 80mm*80mm (L×W) |
| Size of Window Light Mask | 200 mm*40 mm (L×W) |
| Power Requirement | AC: 90~264VAC / 47~63Hz DC: 12V 5A |
| Power Consumption | 60W |
| Dimension | 425mm x 60mm x 130 mm (L×W×H) |
| Weight | 2.5kg / 5.5lbs |
Technical specifications are taken from data published by the supplier; refer to the supplier source for final and binding values.
