UCI Hardness Tester NOVOTEST T-U2
Manufacturer product description
Compact UCI hardness tester for small, thin-walled or complex-shaped parts, used with 10 N, 50 N or 98 N UCI probes and powered by two AA batteries; a Lab version adds a Bluetooth connection to the NOVOTEST Lab app.
UCI Hardness Tester NOVOTEST T-U2
1 more image is not shown on this page.
- Brand
- NOVOTEST
- Category
- Hardness testing / Portable hardness testers
- Method / product family
- Model
- T-U2
Technical Specifications
| UCI probe types | 1kgf (10N) 2.2 lbf; 5kgf (50N) 11lbf; 10kgf (98N) 22lbf |
|---|---|
| Indenter | Diamond indenter (UCI) |
| Measurement hardness range | Factory calibrations: HRC: 20~70; HB: 90~650; HV: 100~750; Tensile strength MPa: 370~1740; User calibrations for any scale and range (for example: 1-3000HV) |
| Hardness scale | UCI probe: HRC, HB, HV, MPa |
| Measurement accuracy | HRC: 2HRC; HB: 10HB; HV: 15HV |
| Materials | UCI probe – pre-calibrated for steel.; Additional custom scales and materials for calibration. |
| Measuring direction | Any direction 360° |
| Standard | ASTM A1038 |
| PC cable connection | Online – novotest.info; Offline – NOVOTEST AWP |
| Wireless connection with Android gadgets via NOVOTEST Lab App | T-U2 – No; T-U2 (Lab) – Yes |
| Storage capacity of measurement results | T-U2 – 256; T-U2 (Lab) – 256 in the device + in NOVOTEST Lab App limited only by the memory of the Android gadgets |
| Language | English; Spanish; Portuguese; French; Russian; *additional languages available by request |
| Dimensions, mm | 122*65*23 |
| Operating temperature range, ° C | -20 to +40 |
| Power | 2pcs AA batteries |
| Bateries life, hours, not less | 20 |
| Weight of electronic unit with batteries, no more, kg | 0.2 |
| Package gross weight, kg | 2 |
Technical specifications are taken from data published by the supplier; refer to the supplier source for final and binding values.
