ACT4000 Paint Thickness Gauge
Üretici ürün açıklaması
ACT4000 is a compact coating thickness gauge. It is designed for non-destructive, fast and precise coating thickness measurement. The principal applications lie in the field of corrosion protection. It is ideal for manufacturers and their customers and specialist advisers, paint shops, electroplaters, chemical, automobile, shipbuilding and aircraft industries and for light and heavy engineers.
ACT4000 Paint Thickness Gauge
- Marka
- AJR
- Kategori
- Thickness Gauge
- Yöntem / ürün ailesi
Teknik Özellikler
| Measuring principle | Magnetic induction & Eddy current |
|---|---|
| Measuring range | (0～1250)μm, depends on probes. maximum 10mm for the probe F10. Refer to Appendix. |
| Memory capacity | Direct mode with 99 storage places and batch mode with 495 locations (5 groups with 99 values each) |
| Memory mode | Automatically or manually |
| Measuring unit | Mil or µm |
| Limits | Minimum and maximum can be preset; with visual and audible alarm when exceeding |
| Low range resolution | 0.1μm |
| Accuracy | ±(3%Thickness+1) μm, depends on probes and conditions |
| Statistic values | Mean, minimum, maximum, number of measurements, standard deviation |
| Delete function | Single data or all data in memory |
| Error warning | Visually or acoustically |
| Probe recognition | Automatic |
| Calibration methods | 2-point or zero calibration |
| Data Port | USB |
| Menu and manual language | English |
| Buttons beep | Adjustable |
| Backlight | Adjustable |
| Shutdown | Manually or automatically |
| Battery capacity indicator | Available |
| Display / Screen | 2.4 inch |
| Power supply | 2 x 1.5 V alkaline batteries |
| Size | 125 x 65 x 30 mm or 4.7" x 2.6" x 0.9" |
| Weight | 340 g (with batteries) or 11 oz |
| Working temperature | -10℃ ～＋ 50℃ ; |
| Storage temperature | -30℃ ～＋ 60℃ ; |
| Relative humidity | ≤90％; |
| Two-point calibration | ±[(1-3)%H +1.5] µm |
Teknik özellikler tedarikçinin yayınladığı verilerden alınmıştır; nihai ve bağlayıcı değerler için tedarikçi kaynağına başvurunuz.
