UDS2-77 SC Ultrasonic Single Flaw Detector for the tram rail
Üretici ürün açıklaması
UDS2-77 SC ultrasonic single rail flaw detector is a mechanized trolley intended for the inspection of one rail line.
UDS2-77 SC Ultrasonic Single Flaw Detector for the tram rail
16 görsel daha bu sayfada gösterilmiyor.
- Marka
- OKOndt Group
- Kategori
- Ultrasonic flaw detectors
- Yöntem / ürün ailesi
Teknik Özellikler
| REPORTS — 1 | Description: Trolley | Q,ty, pcs.: 1 pc. |
|---|---|
| REPORTS — 2 | Description: Guide wheels for symmetrical (standard) rail profile. | Q,ty, pcs.: 2 pcs. | Notes: Guide wheels for rail with groove are installed on the flaw detector by default. |
| REPORTS — 3 | Description: System of couplant supply to probes, including: Tank – 1 pc; Connecting tubes – 1 set; Couplant distributors – 1 set; Controller valves for couplant supply for probe unit – 3 pc; Controller valves main for couplant supply – 1 pc; Nozzle – 1 pc. | Q,ty, pcs.: 1 set |
| REPORTS — 4 | Description: External Loudspeaker | Q,ty, pcs.: 1 pc. |
| REPORTS — 5 | Description: Electronic unit (EU) | Q,ty, pcs.: 1 pc. |
| REPORTS — 6 | Description: Multiplexer Unit (MUX, with BNC connectors) | Q,ty, pcs.: 2 pc. |
| REPORTS — 7 | Description: Battery unit (BU) | Q,ty, pcs.: 1 pc. |
| REPORTS — 8 | Description: GPS module (Detection and fixing of defect coordinates with display in the inspection results) | Q,ty, pcs.: 1 pc. | Notes: Optional. Not included in the base kit price. |
| REPORTS — 9 | Description: Cable set: Power switching unit (PSU) – 1 set; Connection cable (EU-2MUX) – 1 pc; Connection cable (Battery unit – Power switch unit) – 1 pc; Connection cable (Probe-MUX, lemo00-2BNC) – 1 pc; Connection cable (Probe-MUX, 2 lemo00-2BNC) – 1 pc; LAN debugging cable – 1 pc. | Q,ty, pcs.: 1 set. |
| REPORTS — 10 | Description: Encoder | Q,ty, pcs.: 1 pc. |
| REPORTS — 11 | Description: System of rising/lowering of probe unit (controls lever) | Q,ty, pcs.: 3 pc. |
| REPORTS — 12 | Description: Probe Unit #1: 4.0 MHz straight-beam (0°) dual element probe – 1 pc; 2.0 MHz angle-beam (70°) single element probe – 2 pc (d=24mm). | Q,ty, pcs.: 1 set. |
| REPORTS — 13 | Description: Probe Unit #2: 2.0 MHz angle-beam (45°) single element probe (two probes in one housing) – 1 pc; 2.0 MHz angle-beam (55°) single element probe (two probes in one housing) – 1 pc. | Q,ty, pcs.: 1 set. | Notes: Probes with an input angle of 55 degrees are not used when inspecting rails with grooves. |
| REPORTS — 14 | Description: Probe Unit #3: 2.0 MHz angle-beam (70°) single element probe – 2 pc; | Q,ty, pcs.: 1 set. |
| REPORTS — 15 | Description: Probe Unit #4 2.0 MHz angle-beam (70°) single element probe – 2 pc. | Q,ty, pcs.: 1 set. | Notes: Not used when inspecting rails with grooves. |
| REPORTS — 16 | Description: Calibration block “Rail specific gain calibration block” | Q,ty, pcs.: 1 pc. |
| REPORTS — 17 | Description: Manual probes: Probe TSD4-20 (4MHz, 0°, dual element) – 1 pc; Probe TAB2-40-14x14 (2MHz, 45°, single element) – 1 pc; Probe TAB2-55-14x14 (2MHz, 45°, single element) – 1 pc; Probe TAB2-70-14x14 (2MHz, 70°, single element) – 1 pc. | Q,ty, pcs.: 1 set. |
| REPORTS — 18 | Description: Charger | Q,ty, pcs.: 1 pc. |
| REPORTS — 19 | Description: USB-flash card | Q,ty, pcs.: 1 pc. | Notes: Set of technical and operational documentation |
| REPORTS — 20 | Description: Tool kit for service of the flaw detector | Q,ty, pcs.: 1 pc. |
| REPORTS — 21 | Description: Carrying and storage case with lodgment | Q,ty, pcs.: 1 pc. |
| REPORTS — 22 | Description: Protection cover for screen | Q,ty, pcs.: 1 pc. |
| REPORTS — 23 | Description: Sun hood | Q,ty, pcs.: 1 pc. |
| REPORTS — 24 | Description: Spare parts and accessories: Connecting tubes for couplant – 1 set; Fuse – 10 pc; | Q,ty, pcs.: 1 set. |
| REPORTS — 25 | Description: Spare set of ultrasonic units Probe unit #1 – 1 pc; Probe unite #2 – 1 pc; Probe unite #3 – 1 pc; Probe unite #4 – 1 pc; | Notes: Optional. Not included in the base kit price. |
| REPORTS — 26 | Description: Operating documentation: Operating Manual – 1 pc; Passport – 1 pc; Passport “Rail specific gain calibration block” – 1 pc; Operating manual for software “RailInspector” – 1 pc; Maintenance and repair manual – 1 pc; Operating Manual for charger – 1 pc. | Q,ty, pcs.: 1 set |
| REPORTS — 27 | Description: Calibration certificate | Q,ty, pcs.: 1 pc | Notes: Optional. Not included in the base kit price. |
